# -*- coding: utf-8 -*-
"""
Created on Wed Nov 29 07:38:05 2023

@author: aleja
"""
#Testing G-AI created code
#added modifications

import numpy as np
import matplotlib.pyplot as plt #added was missing
import scipy.fft as fft

# Create a sine wave
freq=10
resolution=0.001
t = np.arange(0, freq, resolution)
#freq and 10xfreq
y = 4.0*np.sin(2.0 * np.pi * t)+2.0*np.sin(2.0 * np.pi * 10.0*t)
print("number of points:",freq/resolution)
print (np.max(y))
print (np.min(y))
# Calculate the fft
yf = fft.fft(y)
yfa=np.abs(yf)/np.max(np.abs(yf)) #relative amplitude
yfa=yfa[0:1000]

threshold_of_yffamp=0.2
indexs=np.where(yfa>threshold_of_yffamp) #remember indexs[0] holds the tuples

#convert indexs tuple to list
list_indexs=list(indexs[0])
print("==============")
print("freq,rel-amp")
for index in list_indexs:
    print (index,",",yfa[index])
print("==============")

#limit freq range
freq_range=np.max(indexs)*2
# Plot the fft
plt.close('all')
fig, [plt1,plt2] = plt.subplots(nrows=2, ncols=1)
plt1.plot(t,y,"b.")
plt1.set_xlabel("period")
plt1.set_ylabel("amplitude")
plt1.set_title("Sample data-fictional")


plt2.set_xlim(0,freq_range) #limit x axis freq range
plt2.plot(np.abs(yfa),"r-")
plt2.set_xlabel("freq")
plt2.set_ylabel("relative amp")
plt2.set_title("FFT")
for n in list_indexs:
 plt_text=(str(yfa[n])+","+ str(n))
 plt2.text(n,yfa[n],plt_text)

plt.get_current_fig_manager().window.setGeometry(10,50,1000,500)
plt.tight_layout()

plt.show
